The 300Mbps Concurrent Dual Band Wireless N Gigabit Router delivers unsurpassed Dual Band wireless speed, coverage, and reliability with up to 14x the speed and 6x the coverage of a wireless g connection*.
Concurrent Dual Band technology creates two separate 300Mbps wireless n networks at the same time—one on the 2.4GHz frequency and the other on the less congested 5GHz frequency. A color LCD management interface provides real time performance, security, and device information thereby reducing the need to login to the router.
Share content by connecting USB flash drives, hard drives, or printers directly to two USB ports on the back of the router. Gigabit Ethernet ports offer exceptional wired throughput performance. Multiple Input Multiple Output (MIMO) antenna technology reduces wireless dead spots, advanced wireless encryption protects your digital content, and WMM® Quality of Service (QoS) technology prioritizes gaming, Internet calls, and video streams. Wi-Fi Protected Setup (WPS) connects WPS compliant computers at the touch of a button. Wirelessly stream HD multimedia using the uncongested 5GHz frequency while surfing the Internet using the 2.4GHz frequency.
*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and cover-age will vary depending on interference, network traffic, building materials and other conditions.
| Hardware | | Standards | - Wired: IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX), IEEE 802.3ab (1000Base-TX)
- Wireless: IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n USB 2.0
| | WAN | 1 x 10/100/1000Mbps Auto-MDIX port (Internet) | | LAN | 4 x 10/100/1000Mbps Auto-MDIX port | | USB | 2 x USB 2.0, 1.1 compliant USB type A port | | WPS Button | Wi-Fi Protected Setup (WPS) with other WPS compliant devices | | Connection Type | Dynamic IP, Static (fixed) IP, PPPoE, PPTP | | Router/ Firewall | Enable/disable firewall
NAT, SPI and DoS (block ping, port scan, sync flood)
MAC / Protocol/Domain filtering (deny or allow)
UPnP, DMZ, Static/Dynamic Route support | | LCD | 1.5” x 1.25” color LCD management interface with 4 control buttons | | LCD display | Displays real time performance statistics (2.4GHz, 5GHz, wired switch ports, and Internet connection), device status (2.4GHz, 5GHz, wired switch ports, and Internet connection), management controls (router restart, factory reset, date/time, connected device information), WPS setup, and current PIN information | | LED Indicator | Power | | Power Adapter | 2A external power adapter | | Power Consumption | 1200mA (max) | | Dimension (L x W x H) | 194 x 118 x 38.5 mm (7.6 x 4.6 x 1.5 in.) | | Weight | 365 g (12.8 oz) | | Temperature | - Operation: 0°~ 40°C (32°F~ 104°F)
- Storage: -10°~ 70°C (14°F~158 °F)
| | Humidity | Max. 95% (non-condensing) | | Certifications | CE, FCC | | Wireless | | Frequency | 2.412 ~ 2.484GHz
5.180~5.240GHz / 5.745~5825GHz (a/n) | | Antenna | 2 x 3dBi detachable dipole antennas | | Modulation | OFDM: BPSK, QPSK, 16-QAM, 64-QAM
DBPSK, DQPSK, CCK | | Data Rate | - 802.11a: up to 54Mbps
- 802.11b: up to 11Mbps
- 802.11g: up to 54Mbps
- 802.11n: up to 300Mbps
| | Security | 64/128-bit WEP, WPA-PSK(TKIP)/WPA2-PSK(AES), WPA/WPA2-RADIUS
MAC/Protocol/Domain filter | | QoS | WMM, uplink speed control, IP prioritization | | Output Power | - 802.11a: 14dBm (typical)
- 802.11b: 15dBm (typical)
- 802.11g: 15dBm (typical) 802.11n: 14dBm (typical) with HT20 or HT40
| | Receiving Sensitivity | - 802.11a: -70dBm (typical) @ 54Mbps
- 802.11b: -86dBm (typical) @ 11Mpbs
- 802.11g: -71dBm (typical) @ 54Mbps
- 802.11n: -64dBm (typical) with HT20 or HT40
| | Channels | 2.4GHz: 1~11 (FCC), 1~13 (ETSI)
5GHz: Customer to select channels in compliance with respective local regulations |  |
|
