TEW-430APB Wireless Access Point is today's link to Wireless Technology. Compliant with the IEEE Wireless Networking Standard 802.11g, it provides Direct Sequence Spread Spectrum (DSSS) operation for transparent bridging and roaming capabilities for wireless nodes. The TEW-430APB also provides WDS bridging functions, allowing users to connect two or more Access Points together, wirelessly. With this Wireless Access Point and Wireless Network Adapters, users can connect to Ethernet/Fast Ethernet LAN at home or office to access network resources with coverage up to 300 meters.
| | Hardware | | Standards: | - IEEE 802.11g (Wireless LAN)
- IEEE 802.3u (Fast Ethernet)
| | Media Connector: | 10/100Mbps, Half/Full Duplex | | LED Indicators: | Power, Link, Act | | Power: | 7.5V DC, 1A External Power Adapter | | Dimensions: | 150 x 110 x 30 mm (5.9 x 4.3 x 1.2 inches) (without antenna) | | Weight: | 226g. (8 oz.) | | Temperature: | - Operating: -0° ~ 40°C (32° ~104°F)
- Storage: -25° ~ 70°C (-13° ~ 158°F)
| | Humidity: | Max. 90% (non-condensing) | | Certifications: | CE, FCC | | Wireless | | Frequency Range: | 2.412 ~ 2.484 GHz | | Modulation: | - 802.11b: DSSS
- 802.11g: DBPSK/DQPSK/CCK/OFDM
| | Protocol: | CSMA/CA with ACK | | Data Rates (Auto Fallback): | - 802.11b: 11, 5.5, 2 and 1Mbps
- 802.11g: 54, 48, 36, 24, 18, 12, 9 and 6Mbps
| | Operating Mode: | AP, AP Client, WDS Bridge & Repeater Modes | | Channel: | 1~ 11 Channels (US) 1~13 Channels (EU) | | Security: | - 64/128-Bit WEP (Hex/ASCII), WPA/WPA2
- WPA-PSK/WPA2-PSK
- MAC Address Filter, SSID Broadcasting Control
| | Antenna: | 1 x 2dBi Detachable Diversity Antennas with Female Reverse SMA Connector | | Transmit Power: | 15 dBm ± 2(typical) | | Receiving Sensitivity: | - 11Mbps 8% PER @ -78dBm (typical)
- 54Mbps 10% PER @ -68dBm (typical)
|
|
|
